Miscellaneous Roll Cage Details
Next »
Page 1


 Mustang Trans Am Cage

Here we see the cage on a mid-90's Mustang Trans Am race car. Because the cage is painted white it is easy to see the layout through the front glass. Note the "diamond" shape which transforms the whole windshield into a shear plane. The idea of having upper diagonals in the windshield frame is not unusual, and is often seen in Super Touring cars. But this Trans Am car takes the method right to the limit. It would seem that this type of cage would hinder the driver's outward vision. But the design was used for several years so it cannot have been that bad.
